Strip Heater CF Range

600CF/1000CF

1500CF/2000CF

Product Code: 600CF/1000CF/1500CF/2000CF

The Hot Wire Strip Heater CF Range features:

  • Working lengths are available in 600/1000/1500/2000mm (24/40/59/79in)
  • Temperature controlled PTFE coated contact foils
  • Different foil widths allow materials from 0.2 to 5mm in thickness to be processed
  • Adjustable work stop calibrated in metric & imperial units
  • Clamp beam to prevent bowing during heating cycle
  • Fast cycle times - 0.5mm PVC in 1 second, 2mm PMMA in 15 seconds, 5mm PMMA in 75 seconds
  • Special contact foils available for close centre folds and custom shapes

Price on Application



Features

Bend Length: 600/1000/1500/2000mm (24/40/59/79in)

Max Thickness: 6mm (0.25in)

Single/Double sided heating: N/A (Blade)

Number of Heating Wires per Beam: 2

Max number Heater Beams: 4



This video of the 600DF will give you an idea of how well the CF range Strip Heaters work:



Instructions & Data Sheet

Strip Heater CF range Instructions Download

Technical Data Sheet 1 - Plastic Materials Download

Technical Data Sheet 2 - Local Line Bending Sheets Download
